26 Series - Crimp Style
Parker 26 Series fittings are permanent, crimp-style hydraulic hose fittings engineered for use with Parker braided hoses in low to medium pressure applications. Compatible with the Parkrimp system, these one-piece fittings deliver superior retention, corrosion resistance, and ease of assembly. Designed for quick and secure installation, 26 Series fittings are ideal for a wide range of mobile and industrial hydraulic systems requiring reliable performance and long service life .
Size: -4 to -48 (5 to 76 mm hose bore). - Temperature: set by the hose — -50°C to +150°C across the 201, 206, 213, 266 and 293 families. - Application: crimped ends for low and medium pressure hydraulics, plus refrigerant Tube-O and air brake jounce lines. - Media: rated by the hose — petroleum base hydraulic fluids, refrigerant and air brake. - Pressure: rated by the hose — 12 to 157 bar, falling with bore
Browse 26 Series - Crimp Style by type
3 sub-categories · 5 SKUs total
Male Inverted SAE 45° Swivel 90° Elbow
Female JIC 37° / SAE 45° Dual Flare Swivel
Male Tube-O Rigid - Internal Long Pilot
All products in 26 Series - Crimp Style
Parker 26 Series Female JIC 37˚ / SAE 45˚ - Dual Flare - Swivel - Port Connection 1/2 - Hose ID 13/32 - Steel
-8 3/4"-16 inch Thread
Parker 26 Series Male Inverted SAE 45˚ - Swivel - 90˚ Elbow - Port Connection 1/2 - Hose ID 13/32 - Steel
-8 3/4"-18 inch Thread
