Parker Hannifin Genuine
Product image not available
HDN 3.0 X 24 FF BA CI
Price on RequestLogin for your trade price
excl. VAT · per unit
Trade customer? Sign in for your tier price.
Out of stock · Replenishment on order
Or request a confirmed lead time for this SKU →
Maximum Operating Pressure
Vacuum–550 bar
Size / port thread
4–28 mm
Media
Air / water
Overview
HDN 3.0 X 24 FF BA CI
Specifications
| Maximum Operating Pressure | Vacuum–550 bar |
|---|---|
| Size / port thread | 4–28 mm |
| Media | Air / water |
| Media (detail) | compressed air and industrial water |
| Application (detail) | brass compression fittings making a mechanical grip on rigid and semi-rigid tube |
| Pressure (detail) | 10⁻² millibar (vacuum) to 550 bar. Source: Parker Legris current catalogue, p.105 |
| Size (detail) | 4 to 28 mm |
| Temperature (detail) | not printed in the range specification block — set by the seal and the tube material |
| Catalogue reference (detail) | AGC category: Brass Compression Fittings |
Documents
Catalogues & Literature
Parker Legris - 6 expert tips on how to choose your industrial fitting!
FSC Parker Legris Connectors & Nycoil Tubing Catalog - Cat. 3500LEG/NYC
Parker Legris Rectus - General Catalogue
Brass Compression Fittings Datasheet
FCG FSC Assembly Guides
Compliance · Certifications · Safety
Certificate of conformity - REACH_Statement
Certificate of conformity - RoHS LPCE
Certificate of conformity - Mineral Conflict Statement_connectic
Demos & Tutorials
Enquire about this part
The fastest way to get a price on this SKU is to email our quote desk — your reply lands with an engineer within 4 business hours.
Email a quote request Or use the quote form →
