Parker 77 Series Hose Fitting - Male NPTF Pipe Rigid (AGN) - 2" NPTF - Hose -32 - Stainless Steel
Overview
Parker 77 Series hose fittings are no-skive Parkrimp™ crimp fittings: the hose is crimped straight onto the fitting without stripping the cover, using Parker Parkrimp crimpers and die sets. Each series is matched to specific Parker hose constructions — the approved hose and fitting combinations are listed in Catalogue 4400 — and is available in a full range of end configurations and sizes.
The 10177-32-32C is a Parker 77 Series Hose Fitting with a male NPTF pipe rigid (AGN) end (2" NPTF) for size -32 hose, in stainless steel. Crimped onto the matching Parker hose with Parkrimp equipment (see the hose/fitting table in Catalogue 4400).
Dimensions, pressure ratings and ordering details are on page 392 of the Parker Hydraulic Hoses, Fittings and Equipment CAT/4400/UK, attached under Documents.
Genuine Parker Hannifin product supplied by Applied Group of Companies.
Specifications
| Hose Inside Diameter | -32 (Size), 2" |
|---|---|
| Port Size | 2" |
| Connection Size | 2"-11-1/2" Thread |
| Product Style | Male NPTF Pipe - Rigid |
| Shape | Straight |
| Body Material | Stainless Steel |
| Back-Up Hex Size | 65 mm |
| Specifications Met | SAE J476A / J516 |
| Quantity per Box | 1 |
| Catalogue reference | Parker Hydraulic Hoses, Fittings and Equipment CAT/4400/UK, p.392 |
