Parker Hannifin Genuine
Parker 82 Series Push-Lok Fitting - Female NPTF Pipe - Rigid - Port 3/8" - Hose I.D. -6 - Brass
R547,40
excl. VAT · per unit
Trade customer? Sign in for your tier price.
Made to order · Confirmed on quote
Or request a confirmed lead time for this SKU →
Maximum Operating Pressure
41.0 MPa, 410 bar
Connection 2 Type
Female, NPTF, Rigid
Connection 1 Type
Hose
Overview
Parker 82 Series Push-Lok Fitting - Female NPTF Pipe - Rigid - Port 3/8" - Hose I.D. -6 - Brass
Specifications
| Hose I.D. (size) | -6 |
|---|---|
| Materials of Construction | Brass |
| Body Material | Brass |
| Hex Type | Inch |
| Shape | Straight |
| Port Connection | 3/8" |
| Connection 2 Type | Female NPT Pipe - Rigid |
| Product Style | Female NPTF Pipe - Rigid |
| Country of origin | US |
| Weight | 0.0632 kg |
| Standard pack | 25 |
Genuine Parker Hannifin product supplied by Applied Group of Companies.
Specifications
| Maximum Operating Pressure | 41.0 MPa, 410 bar |
|---|---|
| Body Material | Brass |
| Hex Size | 7/8 inch (see drawing legend H) |
| For Fluid Type | Petroleum Hydraulic Fluids (Petroleum & Water-Glycol Base), Air (General Industrial Air), Fuels - Check fuel type with our catalogue chart., Coolants (Glycol), Lubricants (Oils), Water |
| Product Type | Barbed Fittings, Push-Lok Hose Fittings |
| Connection 2 Type | Female, NPTF, Rigid |
| Hose I.D. (size) | -6 |
| Shape | Straight |
| Port Connection | 3/8" |
| Hex Type | Inch |
| Fitting Length | 46 mm (see drawing legend A) |
| Connection Length | 23 mm (see drawing legend B) |
| Specifications Met | SAE J476A / J516 |
| Application | Machine Tools, Transfer Lines, Paper Machines, Injection Moulding Machines |
| Connection 1 Type | Hose |
| Connection 2 Size | 3/8"-18 inch Thread |
| Connection 1 Size | 9.5 mm Hose I.D., -6 (Size) |
