Parker A-LOK Male Connector to O-Ring Straight Thread - 1/8" Tube O.D. - 5/16-24 SAE - 316 Stainless Steel
Parker A-LOK Male Connector to O-Ring Straight Thread, 1/8" Tube O.D. × 5/16-24 SAE, 316 stainless steel. 593–752 bar, -255 °C to 649 °C.
Overview
Parker A-LOK® is Parker Instrumentation's two-ferrule compression tube fitting. On make-up the front ferrule seals against the fitting body while the Suparcase®-hardened back ferrule grips and supports the tube, giving a leak-tight joint that resists vibration and can be taken apart and remade. A-LOK is the standard choice for instrumentation, sampling and process-control tubing.
The 2M2SC2-316 is a Parker A-LOK Male Connector to O-Ring Straight Thread in 316 stainless steel, connecting 1/8" tube O.D. to 5/16-24 SAE. Configuration: tube to o'ring seal. Overall length 33 mm.
Rated for a working pressure of 593 to 752 bar depending on tube wall thickness and a temperature range of -255 °C to 649 °C. Suitable for liquids, gases, steam, oil, petroleum oil, fuels, natural gas (CNG), hydrogen and others.
Typical applications include CNG / LNG lines, analytical installations, hydrogen service, instrumentation, offshore control panels, research labs and sensing lines, across the chemical, microelectronics, nuclear, oil & gas, petrochemical, power generation, semiconductor and other industries.
Dimensions, pressure ratings and ordering details are on page 60 of the Parker CPI / A-LOK Tube Fittings Catalogue 4230/4233, attached under Documents.
Genuine Parker Hannifin product supplied by Applied Group of Companies.
Specifications
| Connection 1 | 1/8" Tube O.D. |
|---|---|
| Connection 2 | 5/16-24 SAE |
| O-Ring Dash Number | 2-011 |
| Material | 316 Stainless Steel |
| Configuration | Tube to O'Ring Seal |
| Product Style | Male Connector to O-Ring Straight Thread |
| Shape | Straight |
| Length | 33 mm |
| Operating Pressure | 593 to 752 bar |
| Temperature Range | -255 °C to 649 °C |
| For Fluid Type | Gases, Fuels, Steam, Oil, Hydrogen, Natural Gas (CNG), Petroleum Oil, Corrosive, Liquid |
| Application | Instrumentation, Hydrogen Service, Sensing Lines, Analytical Installations, Offshore Control Panels, CNG / LNG Lines, Research Labs |
| Industry | Semiconductor, Petrochemical, Nuclear, Microelectronics, Oil & Gas, Transportation, Power Generation, Chemical |
| Quantity per Box | 5 |
| Catalogue reference | Parker CPI / A-LOK Tube Fittings Catalogue 4230/4233, p.60 |
