Parker Hannifin Genuine
Parker B43/53 Series 3/2 1/8"Bspp Single Foot Pedal / Foot Pedal Return Manual Valve HIGH Temp
R5570,55Login for your trade price
excl. VAT · per unit
Trade customer? Sign in for your tier price.
In stock · Ships from Johannesburg
Valve function
3/2 Midget spool valve
Maximum Operating Pressure
Vacuum to 10 bar
Size / port thread
G1/8 BSPP
Overview
Parker B43/53 Series 3/2 1/8"Bspp Single Foot Pedal / Foot Pedal Return Manual Valve HIGH Temp
Specifications
| Valve function | 3/2 Midget spool valve |
|---|---|
| Maximum Operating Pressure | Vacuum to 10 bar |
| Size / port thread | G1/8 BSPP |
| Temperature Range | -10°C to +80°C |
| Nominal flow Qn | 5,5 l/s (Cv 0,24) |
| Media | air, lubricated or non-lubricated |
| Application | manual / mechanical inline valve — 3/2 1/8"Bspp Single Foot Pedal / Foot Pedal Return Manual Valve HIGH Temp |
| Catalogue reference | Parker Pneumatic B45-53 Midget and Intermediate Manual Valves PDE2623TCUK, p.11 |
Documents
Catalogues Literature
Enquire about this part
The fastest way to get a price on this SKU is to email our quote desk — your reply lands with an engineer within 4 business hours.
Email a quote request Or use the quote form →
