R8 028,55Login for your trade price excl. VAT · per unit
Trade customer? Sign in for your tier price.
On backorder · approx. 30 days
Product type
Rear clevis bracket MP4
Series
Parker P1C / P1F cylinder mountings
For cylinder bore
160 mm

Overview

Parker ISO 15552 Clevis Bracket MP4 160mm (part number P1C-4SMEB) is a Parker rear clevis bracket MP4 for ISO 15552 pneumatic cylinders of 160 mm bore. It gives the cylinder a single-axis pivot at the cap end.

Dimensions follow ISO 15552, so it fits Parker P1F cylinders and any other maker's cylinder built to the same standard and bore. Order to match the cylinder bore; pins and fixings are included where the catalogue lists them.

Genuine Parker product supplied by Applied Group, authorised Parker distributor in South Africa. Dimensions are in the attached catalogue extract.

Specifications

Product type Rear clevis bracket MP4
Series Parker P1C / P1F cylinder mountings
For cylinder bore 160 mm
Compatible cylinder standards ISO 15552
Pressure rating Not applicable — the assembly is rated by the cylinder
Catalogue reference PDE2667TCEN, p.11, 12, 13, 14, 15, 16
