Pivot bracket
Series
Parker P1C / P1F cylinder mountings
For cylinder bore
100 mm and 125 mm

Overview

Parker ISO 15552 Pivot Brackets AT4 For use with MT4 Intermediate Trunnion 100mm and 125mm (part number 9301054266) is a Parker pivot bracket for ISO 15552 pneumatic cylinders of 100 mm and 125 mm bore. It carries the trunnion pins of a trunnion-mounted cylinder.

Dimensions follow ISO 15552, so it fits Parker P1F cylinders and any other maker's cylinder built to the same standard and bore. Order to match the cylinder bore; pins and fixings are included where the catalogue lists them.

Genuine Parker product supplied by Applied Group, authorised Parker distributor in South Africa. Dimensions are in the attached catalogue extract.

Specifications

Product type Pivot bracket
Series Parker P1C / P1F cylinder mountings
For cylinder bore 100 mm and 125 mm
Compatible cylinder standards ISO 15552
Pressure rating Not applicable — the assembly is rated by the cylinder
Catalogue reference Parker P1F Small Bore Cyl, p.17, 27, 31
