Parker Legris Flow Control Regulator 10mm - 3/8" Bspp Male Recessed Adjustment Exh A
Overview
70101017 – Flow Control Regulator 10mm- 3/8″ Bspp Male Recessed Adjustment Exh A
Parker Legris flow control regulators offer precise adjustment, accuracy and compactness providing the solution for all applications. Our flow control regulators are available with polymer, nickel-plated brass, stainless steel and aluminium bodies, with external or recessed adjustment screws. By allowing a higher maximum flow than standards regulators and precise adjustment, this range of products helps you improve your productivity and performance with accuracy.
Features/Benefits:
– Improved Productivity
• Higher maximum flow than standard regulators
• Full flow with minimum pressure drop (model 7060)
• Optimal control of the cylinder rod speed
• 100% leak-tested in production
• Date coding to guarantee quality and traceability
• Reduce compressed air and energy consumption
– Accuracy & Performance
• Precise adjustment for accurate flow regulation from initial to maximum opening
• Constant cylinder rod displacement speed
• Long-term stability of flow
• Reduced weight (polymer version)
• Mechanical strength and corrosion resistance with nickel-plated brass version
Markets:
• Factory Automation
• Vehicle Assembly Facilities
• Food and Beverage
• Semiconductor
• Wearing Apparel
• Packaging Machinery
• Rail
Technical Characteristics:
• Fluids: Compressed Air. Other fluids: contact us
• Materials: Nickel-plated brass, technical polymer, stainless steel, NBR
• Pressure: Vacuum to 10 bar
• Temperature: 0°C to +70°C
Regulations:
• DI: 2002/95/EC (RoHS)
• RG: 1907/2006 (REACH)
• DI: 97/23/EC (PED)
Specifications
| Maximum Operating Pressure | 10 bar |
|---|---|
| Temperature Range | 0°C to +70°C |
| Body Material | Technical Polymer |
| Seal Material | NBR |
| Hex Size | 20 mm |
| Weight | 0.067 kg |
| For Fluid Type | Compressed air, Other fluids: contact us |
| Product Type | Function Fittings and Flow Control |
| Quantity per Box | 10 |
| Connection 1 Size | G 3/8 |
| Connection 2 Size | 10 mm (O.D.) |
| Flow Direction | Exhaust |
| Nut Material | Nickel-Plated Brass |
| Configuration | Port to Tube |
| Height | 37.5 mm |
| Minimum Operating Pressure | 1 bar |
| Connection 1 Type | Male BSPP |
| Application | Robotics, Textile, Automotive Process, Packaging |
| Connection 2 Type | Tube |
| Shape | Elbow 90° |
