Parker Legris Polyurethane PU Ester Tubing 4mm OD 2.5mm ID BLACK - 1000m Drum
Overview
2010U0401 - Parker Legris Polyurethane PU Ester Tubing 4mm OD 2.5mm ID BLACK - 1000m Drum
Polyurethane's 3 specific materials - ether, ester and food-grade "crystal" - offer excellent flexibility and outstanding use in a wide range of applications, allowing for up to 50% space reduction when compared to semi-rigid PA tubing.
Features/Benefits:
- Excellent Mechanical Properties
• Consistent tensile strength for optimum longevity
• Optimal bend radius
• Good vibration absorption
• Unsurpassed abrasion resistance for a single layer tubing
• UV-resistant
• Superior vacuum capability due to surface hardness
• Remaining length marking
• Silicone-free
- 3 Material Grades
• PU ester: perfect for pneumatic applications
• PU ether: no water absorption; superior chemical resistance to PU ester
• PU ether food-grade "crystal": identification of fluids and circuits chemical resistance superior to PU ether improved longevity
Markets:
• Food and Beverage
• Miscellaneous Manufacturing
• Factory Automation
• Vehicle Assembly Facilities
Applications:
• Compressed Air and Industrial Fluids Conveying
• Standard Pneumatic Applications Requiring Rapid Cycles
• Applications Subjected to Water and High Humidity (PU ether)
• Suitable for Vacuum Applications
Technologies:
• PU Tubing
• Polyurethane Tubing
• Industrial Tubing
Technical Characteristics:
• Fluids: Compressed air, industrial fluids (depending on the material type)
• Materials: Polyurethane ester, Polyurethane ether, Polyurethane ether food-grade "crystal"
• Pressure: Vacuum to 12 bar
• Temperature: -20°C to +70°C
Regulations:
Industrial
• DI: 2002/95/EC (RoHS), 2011/65/EC
• DI: 97/23/EC (PED)
• RG: 1907/2006 (REACH)
Food (PU ether food-grade "crystal")
• FDA: 21 CFR 177.2600, 178.3297, 176.170, 178.2010
• RG: 1935/2004 EC
Product Types:
• Polyurethane Ester Tubing
• Polyurethane Ether Tubing
Specifications
| Size / port thread | 3 to 18 mm OD for thermoplastic tubing; 6.3 to 63.5 mm bore for hose |
|---|---|
| Temperature Range | -48°C to +150°C across the range — set by the tube or hose material, so check the individual range |
| Application | pneumatic and low to medium pressure hydraulic lines, plus protective sleeving. Push-Lok hose assembles by hand onto 82 Series fittings; thermoplastic tubing runs into push-in fittings |
| Working media | compressed air, petroleum base hydraulic fluid, lubricating oils, antifreeze, industrial and treated water depending on the tube material |
| Maximum Operating Pressure | 3 to 50 bar depending on the range — polyamide tubing carries the highest working pressure at 50 bar, Push-Lok hose 3 to 28 bar. Source: Parker Catalog 4400 and the Parker Legris current catalogue |
| Catalogue reference | AGC category: Hose, Tubing and Accessories |
