Parker Hannifin Genuine
Parker Lucifer General Purpose 2/2 Brass Valve Direct Operated 1/8"Bsp N/C FKM Orifice 1.5mm - No Coil - Coil Group 1.1
R1579,41Login for your trade price
excl. VAT · per unit
Trade customer? Sign in for your tier price.
Out of stock · Replenishment on order
Or request a confirmed lead time for this SKU →
Function
2 Way Valves 2/2 Valves For Dry Or Lubricated Air, Neutral Gases And Liquids Direct Operated Brass
Orifice
1.5 mm
Kv
0.9 l/min (0.05 m³/h)
Overview
Parker Lucifer General Purpose 2/2 Brass Valve Direct Operated 1/8"Bsp N/C FKM Orifice 1.5mm - No Coil - Coil Group 1.1
Specifications
| Function | 2 Way Valves 2/2 Valves For Dry Or Lubricated Air, Neutral Gases And Liquids Direct Operated Brass |
|---|---|
| Orifice | 1.5 mm |
| Kv | 0.9 l/min (0.05 m³/h) |
| Flow Qn (air) | 70 l/min |
| Operating pressure | 0–20 bar (AC) / 0–12 bar (DC) |
| Fluid temperature | -10°C to +75°C |
| Seat seal | FKM |
| Coil group | 4 |
| Power (AC / DC) | 5 W / 1.1 W |
| Valve code | 121M14 |
| Catalogue reference | Solenoid Valves for Fluid Control General Catalogue 0112UK V2.2 2022, p.22, 62, 522 |
Documents
Catalogues Literature
