Parker Hannifin Genuine
Parker Lucifer General Purpose 3/2 Anodized Aluminium Valve Pilot Operated 1/4"Bsp N/O NBR Orifice 8mm - No Coil - Coil Group 2.1
R17103,38Login for your trade price
excl. VAT · per unit
Trade customer? Sign in for your tier price.
Out of stock · Replenishment on order
Or request a confirmed lead time for this SKU →
Maximum Operating Pressure
40 bar AC/DC
Body Material
Anodized aluminium
Function
NORMALLY OPEN
Overview
Parker Lucifer General Purpose 3/2 Anodized Aluminium Valve Pilot Operated 1/4"Bsp N/O NBR Orifice 8mm - No Coil - Coil Group 2.1
Specifications
| Function | NORMALLY OPEN |
|---|---|
| Maximum Operating Pressure | 40 bar AC/DC |
| Body Material | Anodized aluminium |
| Seal Material | NBR |
| Valve Type | 3/2 way |
| ATEX Specifications Met | - |
| Flow Coefficient | 10 l/min |
| Maximum Fluid Temperature | +75°C |
| Orifice Size | 8 mm |
| Port Size | G 1/4 |
| Port Type | PIPE MOUNTING |
| Specifications Met | Pilot seat discs in Kel-F (PCTFE); valve with pilot return pipe. |
| Minimum Fluid Temperature | -10 °C |
| Minimum Operating Pressure | 1 bar (AC or DC) |
| Actuation Type | Pilot Operated |
| Media | air, Neutral Gases, Oil |
| Insulation Class | n/a |
