Parker Hannifin Genuine
Parker Lucifer General Purpose 3/2 Anodized Aluminium Valve Pilot Operated Sub-Base N/O NBR Orifice 15mm c/w Manual Override - No Coil - Coil Group 2.1/3.0
R16382,56Login for your trade price
excl. VAT · per unit
Trade customer? Sign in for your tier price.
On backorder · approx. 40 days
Or request a confirmed lead time for this SKU →
Maximum Operating Pressure
10 bar AC/DC
Body Material
Anodized aluminium
Function
NORMALLY CLOSED
Overview
Parker Lucifer General Purpose 3/2 Anodized Aluminium Valve Pilot Operated Sub-Base N/O NBR Orifice 15mm c/w Manual Override - No Coil - Coil Group 2.1/3.0
Specifications
| Function | NORMALLY CLOSED |
|---|---|
| Maximum Operating Pressure | 10 bar AC/DC |
| Body Material | Anodized aluminium |
| Seal Material | NBR |
| Valve Type | 3/2 way |
| Actuation Type | PILOT OPERATED |
| Coil Power Consumption | - |
| Coil Temperature Range | - |
| Electrical Connection | - |
| Flow Coefficient | 5000 l/min |
| Port Type | - |
| Minimum Operating Pressure | 0.5 bar AC/DC |
| Coil Specifications Met | - |
| Orifice Size | 15 mm |
| ATEX Specifications Met | - |
| Maximum Fluid Temperature | +75°C |
| Catalogue reference | Parker Lucifer Solenoid Valves General Catalogue 0112UK, p.206, 525 |
