Parker Lucifer General Purpose 5/2 Single Solenoid / Spring Return POM Valve Pilot Operated CETOP Sub-Base FKM Orifice 6mm c/w Manual Override + Flow Regulator - No Coil - Coil Group 2.1/3.0
Overview
The L Series of Heavy Duty Poppet valves includes many product solutions for Valve Actuation in the Process Industry. This range delivers an unmatched high flow performance, up to 1400 l/min. The poppet design and materials makes this product extremely reliable either for low and high frequency applications making it the best choice for critical process control applications. This product solution modularity in combination with our ATEX coils program can optimize the total ownership costs delivering high reliability, extreme flexibility and best competitiveness.
Markets:
- Pharmaceutical
- Chemicals Production
- Refineries
- Food & Beverage production, storage
- Air & Gases production and treatment
Applications:
- Valve Actuation
Features/Benefits:
- SIL approved by third party
- Coil modularity
- Multiapproved coil including Atex
Specifications
| Maximum Operating Pressure | 0.5–40 bar |
|---|---|
| Size / port thread | 1/8"–1/2" |
| Temperature Range | -40°C to +120°C |
| Working media | compressed air and neutral gases; anodised aluminium bodies, with POM and 316L stainless variants |
| Application | 5/2 and 5/3 pneumatic distributors — double-acting cylinder control, spring return, differential or double solenoid |
| Pressure (detail) | up to 40 bar; minimum 0.5 to 2.5 bar depending on function. Source: Parker Solenoid Valves for Fluid Control, General Catalogue 0112UK |
| Size (detail) | ports 1/8" to 1/2" and sub-base; orifice 4 to 15 mm |
| Temperature (detail) | fluid -40°C to +120°C, set by the seat seal — mostly nitrile, with FKM and PUR options |
| Catalogue reference | AGC category: Lucifer 5/2 5/3 Pneumatic Distributors |
