Parker Hannifin Genuine
Parker Lucifer ZB12 Standard Coil 24Vdc Class F. Form A. IP65. Coil Group 20.1 - W/O Din Plug
R653,68
excl. VAT · per unit
Trade customer? Sign in for your tier price.
Out of stock · Replenishment on order
Or request a confirmed lead time for this SKU →
Size / port thread
DIN plug connection
Temperature Range
As the host unit
Application
coils for DIN plug connection
Overview
304020 - Parker Lucifer ZB12 Standard Coil 24Vdc Class F. Form A. IP65. Coil Group 20.1 - W/O Din Plug
Suitable for all Parker Lucifer valves corresponding to coil group 20.1.
Coil manufactured with F class copper wire, moulded in thermoplastic material polyester with 30% glass fiber.
IP65 protection rate with EN 175301-803:2006-A. Three pin connector.
This coil conforms to the IEC/CENELEC safety standards and complies with European low-voltage directive.
For UL recognized version: UL file MH19410.
DIN plug connector to be ordered separately (see coil accessories section).
Specifications
| Size / port thread | DIN plug connection |
|---|---|
| Temperature Range | As the host unit |
| Application | coils for DIN plug connection |
| Pressure | As the host unit |
| Size | DIN plug connection, form |
| Temperature | As the host unit |
| Catalogue reference (detail) | AGC category: Coil Group 20.1 |
| Temperature Range (detail) | as the coil group and voltage code |
| Size (detail) | DIN plug connection, form A and form B |
| Temperature (detail) | as the coil group and voltage code — check the individual part |
| Pressure (detail) | as the valve it operates. Range STAMP — Parker Solenoid Valves for Fluid Control, General Catalogue 0112UK, p.415 |
| Application (detail) | coils for DIN plug connection. A coil fits a valve by coil GROUP, not by voltage or physical size — groups 1.1 to 14.3 cover standard, high-flow, reduced-power, bistable, intrinsically safe, manual-reset, transportation and oil-burner duties |
