Maximum Operating Pressure
10 bar
Stroke
60 mm
Bore
25 mm

Overview

Parker P1A Series ISO 6432 25mm Bore x 60mm Stroke Mini Round Cylinder STD Temp c/w Magnet Adj Cushion

Source: appliedgroup.co.za ↗

Specifications

Standard ISO 6432 mini round cylinder
Bore 25 mm
Stroke 60 mm
Action Double acting, adjustable cushioning
Maximum Operating Pressure 10 bar
Working media Dry, filtered compressed air (ISO 8573-1 class 3.4.3)
Seals Standard NBR
Temperature Range -20°C to +80°C
Piston Magnetic piston
Piston rod diameter 10 mm
Piston rod thread M10x1.25
Port thread G1/8
Theoretical force at 6 bar (out) 295 N
Theoretical force at 6 bar (return) 247 N
Catalogue reference PDE2564, p.6, 13, 14, 15
