Parker Phastite Permanent Union Equal Elbow - 1" Tube O.D. - 316 Stainless Steel
Parker Phastite Permanent Union Equal Elbow, 1" Tube O.D., 316 stainless steel. 1550 bar, -45 °C to 93 °C.
Overview
Parker Phastite® is a permanent, ferrule-less tube connection made in under two minutes with a hand-held hydraulic tool — no welding, threading or hot work — for high-pressure process and instrumentation lines. Phastite connections are DNV type-approved.
The PH-16-PE-SS is a Parker Phastite Permanent Union Equal Elbow in 316 stainless steel, for 1" tube O.D. Configuration: tube to tube.
Rated for a maximum working pressure of 1550 bar and a temperature range of -45 °C to 93 °C.
Typical applications include chemical injection, hydraulic power unit, remote operated vehicle, semiconductor and top side umbilical termination unit.
Dimensions, pressure ratings and ordering details are on page 161 of the Parker Instrumentation Fittings, Materials & Tubing Guide, attached under Documents.
Genuine Parker Hannifin product supplied by Applied Group of Companies.
Specifications
| Connection 1 | 1" Tube O.D. |
|---|---|
| Connection 1 Size | 1" |
| Connection 2 Size | 1" |
| Material | 316 Stainless Steel |
| Configuration | Tube to Tube |
| Fitting Type | Ferruleless, Tube to Tube |
| Connection Type | Permanent |
| Shape | Elbow |
| Maximum Operating Pressure | 1550 bar |
| Temperature Range | -45 °C to 93 °C |
| Application | Remote Operated Vehicle, Semiconductor, Top Side Umbilical Termination Unit, Hydraulic Power Unit, Chemical Injection |
| Specifications Met | DNV |
| Assembly Time | < 2 Minutes |
| Quantity per Box | 1 |
| Catalogue reference | Parker Instrumentation Fittings, Materials & Tubing Guide, p.161 |
