Parker Hannifin Genuine
Parker PS1 Series 6mm Double Air Supply Head and Tail Set
R1267,48
excl. VAT · per unit
Trade customer? Sign in for your tier price.
In stock · Ships from Johannesburg
Maximum Operating Pressure
3–8 bar
Size / port thread
6–200 mm
Temperature Range
-15°C to +60°C
Overview
Parker PS1 Series 6mm Double Air Supply Head and Tail Set
Specifications
| Maximum Operating Pressure | 3–8 bar |
|---|---|
| Size / port thread | 6–200 mm |
| Temperature Range | -15°C to +60°C |
| Working media | air or inert gas, filtered 40 µ, dry or lubricated |
| Application | PS1 modular interface valve. Changeover 10 ms actuate / 15 ms return on 3/2, 15 / 20 ms on 4/2. Vibration 2 g at 2 to 150 Hz (IEC68-2-6), impact 15 g 11 ms (IEC68-2-27) |
| Pressure (detail) | 3 to 8 bar; the low-pressure module runs 1 to 8 bar on 3/2 only. Source: Parker PS1 Modular Interface Valve, PDE2626TCUK |
| Size (detail) | valve port tube Ø6 mm; Qn 120 Nl/min, Qmax 200 Nl/min |
| Temperature (detail) | -15°C to +60°C working; -40°C to +70°C storage |
| Catalogue reference | AGC category: PS1 Series Valve |
