Parker Hannifin Genuine
Parker PVL-B Series 1/8" Single Air Supply Head and Tail Set - Surface
R1001,91
excl. VAT · per unit
Trade customer? Sign in for your tier price.
Out of stock · Replenishment on order
Or request a confirmed lead time for this SKU →
Maximum Operating Pressure
3–10 bar
Size / port thread
1/8"–3/8"
Temperature Range
-15°C to +60°C
Overview
Parker PVL-B Series 1/8" Single Air Supply Head and Tail Set - Surface
Specifications
| Maximum Operating Pressure | 3–10 bar |
|---|---|
| Size / port thread | 1/8"–3/8" |
| Temperature Range | -15°C to +60°C |
| Working media | air or inert gas, filtered 40 µ, dry or lubricated |
| Application | PVL-B and PVL-C inline valves. Surface mount, or stack on 35 mm DIN rail. Glass-filled polyamide body, polyurethane seals, brass fittings |
| Pressure (detail) | 3 to 10 bar (2 to 10 bar on the low-pressure variants). Range STAMP — Parker PVL-B & PVL-C Inline Valves, PDE2628TCUK |
| Size (detail) | PVL-B 1/8" (tube Ø6 mm, head/tail 1/4", Qn 540 Nl/min, Qmax 900 Nl/min); PVL-C 1/4" (tube Ø8 mm, head/tail 3/8", Qn 1100 Nl/min, Qmax 1800 Nl/min) |
| Temperature (detail) | -15°C to +60°C working; -40°C to +70°C storage |
| Catalogue reference | AGC category: PVL-B Series |
