Product type
Trunnion MT4
Series
Parker P1C / P1F cylinder mountings
For cylinder bore
40 mm

Overview

PARKER TRUNNION P1F-S040 PROFILE (part number P1C-4LMY) is a Parker trunnion MT4 for ISO 15552 pneumatic cylinders of 40 mm bore. It lets the cylinder pivot about its centreline.

Dimensions follow ISO 15552, so it fits Parker P1F cylinders and any other maker's cylinder built to the same standard and bore. Order to match the cylinder bore; pins and fixings are included where the catalogue lists them.

Genuine Parker product supplied by Applied Group, authorised Parker distributor in South Africa. Dimensions are in the attached catalogue extract.

Source: appliedgroup.co.za ↗

Specifications

Product type Trunnion MT4
Series Parker P1C / P1F cylinder mountings
For cylinder bore 40 mm
Pressure rating Not applicable — the assembly is rated by the cylinder
Catalogue reference Parker P1F Small Bore Cyl, p.17, 27, 31, 33, 37
