DX Series ISO 5599-1 Valves

The Parker DX ISOMAX series is a modular range of ISO 5599-1 pneumatic valves available in sizes 1, 2, and 3. These 5/2 and 5/3 subbase-mounted valves feature a durable ceramic seat that provides excellent resistance to contamination, making them ideal for demanding industrial environments. Each valve coil is plug-wired with a 20 mm or 30 mm DIN connector for fast installation and reliable operation. Flow capacity is up to 1100 L/min for ISO 1, 2200 L/min for ISO 2 , and 3100 L/min for ISO 3, making the series suitable for a wide range of high-speed automation applications.

Size: ISO 5599-1 sizes 1, 2 and 3 and ISO 15407-1 sizes 01 and 02. Flow Qn 6.3 to 64 l/s, Qmax 10.6 to 101 l/s. - Temperature: -10°C to +60°C. - Application: ISO-standard sub-base mounted directional valves — 5/2 spring return, 5/2 differential, 5/2 double solenoid and 5/3. - Media: air or inert gas, filtered 40 micron class 5 and dry class 4 to ISO 8573-1, non-lubricated or lubricated. - Pressure: 10 bar maximum on solenoid versions, 12 bar on the pneumatic version. Minimum 1 to 4 bar depending on size and function — a 5/2 spring return needs 4 bar on size 01/02, a double solenoid only 1 bar on sizes 2 and 3. Source: Parker ISOMAX DX ISO Valve Series, PDE2568TCUK, pp.8 and 9
