Vortec Compressed Air Products

Size: 1/8" to 1/2" NPT compressed air inlets; air knives 76 to 610 mm (3" to 24"); air flow amplifiers 10 to 76 mm throat; vortex tubes 100 to 6 000 BTU/hr (29 to 1 758 W) on 2 to 100 SCFM (57 to 2 830 SLPM). - Temperature: cold air guns reach -23°C (-10°F) minimum at 20°C (70°F) inlet air; the 609 hot air gun reaches +93°C (200°F) maximum outlet; the cooling tube gives a 33°C (60°F) drop. - Application: spot cooling, enclosure cooling, blow-off, drying, conveying, part cleaning, spray and humidification, and drum filling and emptying — no moving parts and no refrigerant. - Media: clean, dry compressed air filtered to 5 micron; the spray nozzles additionally handle water and liquids to 1 100 cPs. - Pressure: every Vortec specification is published at a 100 psig (6,9 bar) reference condition and the sheets print no maximum supply pressure. Air knives are tabulated 4,1 to 6,9 bar (60 to 100 psig); the drum pump must not run below 3,5 bar (50 psig). Range STAMP — Vortec spec sheets, vortec.com, 2026
