Parker Hannifin Genuine
ITW Vortec Standard Cold Air Gun. Part No: 630
R18739,46
excl. VAT · per unit
Trade customer? Sign in for your tier price.
On backorder · 2 weeks
Or request a confirmed lead time for this SKU →
Size / port thread
1/4" NPT (F)
Temperature Range
-1°C (30°F) min achieved
Nominal flow Qn
35 SCFM (991 SLPM)
Specifications
| Size / port thread | 1/4" NPT (F) |
|---|---|
| Temperature Range | -1°C (30°F) min achieved |
| Nominal flow Qn | 35 SCFM (991 SLPM) |
| Cooling capacity | 2 500 BTU/hr (733 W) |
| Application | spot cooling of machining, grinding, welding and soldering, electronics test and needle cooling |
| Media | clean, dry compressed air, 5 micron filtered |
| Reference pressure | Specifications are for 100 psig (6,9 bar) compressed air; no maximum supply pressure is published. |
| Catalogue reference | Vortec spec sheet – Cold Air Gun – Models 610, 620, 630 |
