Parker Hannifin Genuine
Parker 3/2 Low Lead Brass Valve Direct Operated 1/4"Bsp N/C FKM/FDA Orifice 3mm - 110Vac Coil
R1915,70Login for your trade price
excl. VAT · per unit
Trade customer? Sign in for your tier price.
Out of stock · Replenishment on order
Or request a confirmed lead time for this SKU →
Body Material
CW510L Low Lead Brass
Function
Normally Closed (NC)
Seal Material
FDA FKM
Overview
Parker 3/2 Low Lead Brass Valve Direct Operated 1/4"Bsp N/C FKM/FDA Orifice 3mm - 110Vac Coil
Specifications
| Function | Normally Closed (NC) |
|---|---|
| Body Material | CW510L Low Lead Brass |
| Seal Material | FDA FKM |
| Valve Type | 3-Way |
| Product Series | Low Lead Brass Solenoid Valves |
| Orifice 1 Size (mm) | 3 |
| Voltage (V) | 110VAC/50Hz - 120VAC/60Hz |
| Coil Type | UL Recognized Coil, DIN plug connection, 32 mm |
| Port Size | G 1/4 |
| Media | Superheated Water and Steam |
| Flow Coefficient 1 | 0.22 m3/hour, 3.7 L/min |
| Coil Specifications Met | IP65 (with DIN plug), Insulation Class F (155°C) (with DIN plug) |
| Actuation Type | Direct Operated |
| Orifice 1 Size | 3 mm |
| Power Consumption | 11 W |
| Flow Coefficient 2 | n/a |
| Maximum Pressure Differential | 6 bar |
| Number of Ports | 3 |
| Port Type | BSP |
| Minimum Fluid Temperature | -10 °C |
| Orifice 2 Size | n/a |
| Input Voltage | 110 VAC/50Hz |
| Catalogue reference | Solenoid Valves for Fluid Control General Catalogue 0112UK V2.2 2022, p.224, 523 |
