Parker Hannifin Genuine
Parker 82 Series Push-Lok Fitting - Female BSP Parallel Pipe - Swivel (60° Cone) - Port 1/2" - Hose I.D. -8 - Steel
R317,47
excl. VAT · per unit
Trade customer? Sign in for your tier price.
Made to order · Confirmed on quote
Or request a confirmed lead time for this SKU →
Maximum Operating Pressure
430 bar, 43.0 MPa
Connection 2 Type
Swivel, Female, 60° Cone, BSP Parallel Pipe
Connection 1 Type
Hose
Overview
Parker 82 Series Push-Lok Fitting - Female BSP Parallel Pipe - Swivel (60° Cone) - Port 1/2" - Hose I.D. -8 - Steel
Specifications
| Connection 2 Type | Female BSP Parallel Pipe - Swivel (60° Cone) |
|---|---|
| Body Material | Steel |
| Hose I.D. (size) | -8 |
| Materials of Construction | Steel |
| Shape | Straight |
| Port Connection | 1/2" |
| Hex Type | Metric |
| Product Style | Female BSP Parallel Pipe - Swivel (60° Cone) |
| Country of origin | DE |
| Weight | 0.0768 kg |
| Standard pack | 25 |
Genuine Parker Hannifin product supplied by Applied Group of Companies.
Specifications
| Maximum Operating Pressure | 430 bar, 43.0 MPa |
|---|---|
| Body Material | Steel |
| Hex Size | 27 mm (see drawing legend W) |
| For Fluid Type | Fuels - Check fuel type with our catalogue chart., Lubricants (Oils), Air (General Industrial Air), Water, Petroleum Hydraulic Fluids (Petroleum & Water-Glycol Base), Coolants (Glycol) |
| Product Type | Barbed Fittings, Push-Lok Hose Fittings |
| Connection 2 Type | Swivel, Female, 60° Cone, BSP Parallel Pipe |
| Hose I.D. (size) | -8 |
| Shape | Straight |
| Port Connection | 1/2" |
| Hex Type | Metric |
| Connection 1 Type | Hose |
| Fitting Length | 42 mm (see drawing legend A) |
| Application | Injection Moulding Machines, Machine Tools, Paper Machines, Transfer Lines |
| Connection Length | 15 mm (see drawing legend B) |
| Connection 2 Size | 1/2"-14 inch Thread |
| Connection 1 Size | -8 (Size), 12.7 mm Hose I.D. |
| Port Type | DKR |
| Specifications Met | BS 5200-A |
