Parker ISO 15552 Front Flange MF1/MF2 320mm
Parker Front / rear flange MF1/MF2 for ISO 15552 cylinders, Ø320 mm.
Overview
Parker ISO 15552 Front Flange MF1/MF2 320mm (part number P1C-4WMB) is a Parker front / rear flange MF1/MF2 for ISO 15552 pneumatic cylinders of 320 mm bore. It bolts the cylinder through a panel or frame at either end cap.
Dimensions follow ISO 15552, so it fits Parker P1F cylinders and any other maker's cylinder built to the same standard and bore. Order to match the cylinder bore; pins and fixings are included where the catalogue lists them.
Genuine Parker product supplied by Applied Group, authorised Parker distributor in South Africa. Dimensions are in the attached catalogue extract.
Specifications
| Product type | Front / rear flange MF1/MF2 |
|---|---|
| Series | Parker P1C / P1F cylinder mountings |
| For cylinder bore | 320 mm |
| Compatible cylinder standards | ISO 15552 |
| Pressure rating | Not applicable — the assembly is rated by the cylinder |
| Catalogue reference | PDE2667TCEN, p.11, 12, 13, 14, 15, 16 |
