Parker Hannifin Genuine
Parker Legris Braided Self-Fastening NBR Hose 1/2" Black Per Metre
R9445,99Login for your trade price
excl. VAT · per unit
Trade customer? Sign in for your tier price.
In stock · Ships from Johannesburg
Maximum Operating Pressure
16 bar, 1.6 MPa
Temperature Range
-20°C to +100°C
Outside Diameter
19 mm
Overview
Parker Legris Braided Self-Fastening NBR Hose 1/2" Black Per Metre
Specifications
| Maximum Operating Pressure | 16 bar, 1.6 MPa |
|---|---|
| Temperature Range | -20°C to +100°C |
| Outside Diameter | 19 mm |
| Weight | 0.23625 kg/m, 9.450 kg/package |
| Compatible Fitting | Quick-Acting Barbed Fittings (with Brass Male BSPP Thread), Quick-Acting Barbed Fittings (with Brass Female Compression Fitting), Quick-Acting Barbed Fittings (with Brass Male BSPT Thread) |
| Product Type | Coolant Hose, Pneumatic Hose |
| Region of Origin | France |
| Cover Color | Black |
| Hose Inside Diameter | 0.5 INCH |
| Hose Outside Diameter | 0.748 INCH |
| Length per Package | 40 m |
| Media | Water, Fuels (Oil & Petroleum), Air (Pneumatics) |
| Specifications Met | REACH, CNOMO: E07.21.115N, NF T46 019, NF T47 252, RoHS 2011/65/EC |
| Design Factor | 3 |
| Inside Diameter | 12.7 mm |
| Disclaimer | CAUTION: CNOMO certification is valid exclusively for Red and Green hose only when connected to Legris’ CNOMO-certified Barb Connectors 0132 |
| Package Type | Reel |
| Application | Cooling, Industrial Machinery, Pneumatics, Welding Robots, In-Plant Automotive |
| Minimum Bend Radius | 120 mm |
| Hose Reinforcement Material | Braid of Textile |
| Cover Material | Nitrile Butadiene Rubber (NBR) |
| Number of Tubes | 1 |
| Hose Inner Tube Material | Nitrile Butadiene Rubber (NBR) |
| Maximum Operating Temperature | 100 °C |
| Minimum Operating Temperature | -4 °F |
| Division | Low Pressure Connectors Europe Division |
| Brand | Legris |
| Technology | Fluid & Gas Handling |
| Industry | Industrial Manufacturing Equipment |
Documents
Catalogues & Literature
Technical Tubing And Hose
Self-Fastening-NBR-Hose Datasheet
Parker Legris Rectus - General Catalogue
Tubing Part Number Identification
Packaging For Technical Tubing And Hose
