Parker Hannifin Genuine
Parker Legris Braided Self-Fastening NBR Hose 5/8" Black Per Metre
R13600,56Login for your trade price
excl. VAT · per unit
Trade customer? Sign in for your tier price.
In stock · Ships from Johannesburg
Maximum Operating Pressure
1.6 MPa, 16 bar
Temperature Range
-20°C to +100°C
Outside Diameter
23 mm
Overview
Parker Legris Braided Self-Fastening NBR Hose 5/8" Black Per Metre
Specifications
| Maximum Operating Pressure | 1.6 MPa, 16 bar |
|---|---|
| Temperature Range | -20°C to +100°C |
| Outside Diameter | 23 mm |
| Weight | 0.325 kg/m, 13 kg/package |
| Compatible Fitting | Quick-Acting Barbed Fittings (with Brass Male BSPP Thread), Quick-Acting Barbed Fittings (with Brass Male BSPT Thread), Quick-Acting Barbed Fittings (with Brass Female Compression Fitting) |
| Product Type | Coolant Hose, Pneumatic Hose |
| Region of Origin | France |
| Cover Color | Black |
| Hose Inside Diameter | 0.625 INCH |
| Hose Outside Diameter | 0.905 INCH |
| Length per Package | 40 m |
| Disclaimer | CAUTION: CNOMO certification is valid exclusively for Red and Green hose only when connected to Legris’ CNOMO-certified Barb Connectors 0132 |
| Application | In-Plant Automotive, Industrial Machinery, Cooling, Pneumatics, Welding Robots |
| Number of Tubes | 1 |
| Specifications Met | REACH, NF T46 019, CNOMO: E07.21.115N, RoHS 2011/65/EC, NF T47 252 |
| Cover Material | Nitrile Butadiene Rubber (NBR) |
| Package Type | Reel |
| Hose Inner Tube Material | Nitrile Butadiene Rubber (NBR) |
| Design Factor | 3 |
| Media | Fuels (Oil & Petroleum), Water, Air (Pneumatics) |
| Inside Diameter | 15.9 mm |
| Minimum Bend Radius | 140 mm |
| Hose Reinforcement Material | Braid of Textile |
Documents
Catalogues & Literature
Technical Tubing And Hose
Self-Fastening-NBR-Hose Datasheet
Parker Legris Rectus - General Catalogue
Tubing Part Number Identification
Packaging For Technical Tubing And Hose
