Parker Legris LF3800 Pre-Grooving Tool For Metalic Tubing
Overview
The Parker Legris LF3800 Pre-Grooving Tool is designed to prepare metallic tubing for seamless connection with push-to-connect fittings in low-pressure water and fluid systems. This tool simplifies installation by creating consistent groove profiles in tubing of all diameters, ensuring reliable sealing with Legris LF3800 connectors. The stainless steel AISI 316L construction provides corrosion resistance in demanding environments, whilst the FKM seal material ensures compatibility with food-grade applications. Operating safely at pressures up to 14.5 psi, the pre-grooving tool minimises connection preparation time and reduces the risk of improper seating. Compliant with USDA NSF H1 specifications, this single-unit tool is ideal for technicians working in pharmaceutical manufacturing, water treatment, and food processing facilities where hygienic, leak-free connections are essential.
Specifications
| Connection Type | n/a |
|---|---|
| Maximum Operating Pressure | n/a |
| Temperature Range | n/a to +n/a |
| Body Material | Stainless Steel AISI 316L |
| Seal Material | FKM |
| Weight | 0.361 kg |
| For Fluid Type | Other Fluids: Please Consult Us, Air, Water |
| Product Series | LF 3800 |
| Product Type | Push-to-Connect Fittings |
| Quantity per Box | 1 |
| Configuration | n/a |
| Connection 1 Size | All Diameters |
| Shape | n/a |
| Connection 2 Type | n/a |
| Vacuum Pressure Rating | 1 bar, 755 mm-Hg |
| Specifications Met | PED DI: 97/23/EC, REACH DI: 1907/2006, FDA 21 CFR, RoHS DI: 2002/95/EC, ATEX DI: 94/9/EC, ISO 14743 (Pneumatic Transmissions), EC 1935/2004, RoHS DI: 2011/65/EC, UL 94 V-0 (Seal), USDA NSF H1 (Grease) |
| Connection 1 Type | Tube |
| Application | Pharmaceutical, Food Processing, Chemicals, Medical Equipment, Petrochemicals, Paper Industry |
| Connection 2 Size | n/a |
