Parker Hannifin Genuine
Parker Legris Polyethylene PE Advanced Tubing 14mm OD 11mm ID Clear 75m Drum
R2334,20Login for your trade price
excl. VAT · per unit
Trade customer? Sign in for your tier price.
On backorder · approx. 55 days
Or request a confirmed lead time for this SKU →
Maximum Operating Pressure
16 barg
Temperature Range
-40°C to +95°C
Weight
5.850 kg/package
Overview
Parker Legris Polyethylene PE Advanced Tubing 14mm OD 11mm ID Clear 75m Drum
Specifications
| Maximum Operating Pressure | 16 barg |
|---|---|
| Temperature Range | -40°C to +95°C |
| Weight | 5.850 kg/package |
| Tube I.D. (mm) | 11 |
| Tube O.D. (inch) | na |
| Tube O.D. (mm) | 14 |
| Length (m) | 75 |
| Color | NATURAL |
| Tube I.D. (inch) | na |
| Length (inch) | na |
| Media | Beverages (Advanced PE), Other Fluids (Advanced PE), Water (Advanced PE), Industrial Fluids (Low density PE) |
| Application | Water, Food Processing, Chemicals, Petrochemicals, Beverage, Water Treatment |
| Specifications Met | RG: 1935/2004/EC (Advanced PE Tubing), RoHS 2011/65/EC (Advanced PE Tubing), PED 97/23/EC (Advanced PE Tubing), FDA 21 CFR 177.1520 (Advanced PE Tubing), NSF 51 (Advanced PE Tubing), RoHS 2002/95/EC (Advanced PE Tubing), NSF 61 C-HOT (Advanced PE Tubing) |
| Number of Tubes | 1 |
| Vacuum Pressure Rating | 755 mm-Hg |
| Catalogue reference | Parker Legris Rectus Distribution Catalogue (Europe), p.404 |
