Parker Legris Semi-Rigid 8 Polyamide PA Tubing 5mm OD 3,3mm ID Black 25m Roll
Overview
Parker Legris and Rectus are Parker's brands for low-pressure pneumatic connections — push-in fittings, brass compression fittings, quick-couplers, tubing and blowguns. Engineered for industrial and process pneumatic systems, these connection products are renowned for fast, reliable assembly, compliance with international thread and sealing standards (BSPP, BSPT, NPT, metric), and consistent quality across the EU, NA and APAC distribution network.
Markets:
- Industrial automation
- Pneumatic actuator control
- Process and instrument air
- Mobile / heavy-duty equipment
- Robotics and material handling
Applications:
- Compressed air distribution and routing
- Pneumatic cylinder, valve and tool connections
- Tubing and hose terminations
- Quick disconnect for tooling and inspection
Features/Benefits:
- Multiple thread standards (BSPP, BSPT, NPT, metric)
- Brass, stainless steel and polymer body options
- Push-in, compression and quick-coupler styles
- ISO-standard interchange (where applicable)
- Wide working pressure and temperature range
- Compliance with PED, REACH, RoHS and ATEX (where applicable)
Reference: Parker Legris & Rectus Distribution Catalogue CAT/0214/UK (2020).
Specifications
| Maximum Operating Pressure | 50 bar |
|---|---|
| Temperature Range | -40°C to +up to 100°C See the Graph “Working Pressure/Working Temperature” |
| Weight | 0.28 kg/package |
| Tube O.D. (mm) | 5 |
| Tubing Material | PA |
| Color | BLACK |
| Length (m) | 25 |
| Tube I.D. (mm) | 3,3 |
| Application | Industrial Machinery, Robotics, Tooling, Packaging, Motion Technologies, Compressed Air |
| Specifications Met | PED 97/23/EC (Industrial), RoHS 2002/95/EC, 2011/65/EC (Industrial), REACH 1907/2006 (Industrial) |
| Vacuum Pressure Rating | 755 mm-Hg |
| Number of Tubes | 1 |
| Media | Air (Compressed Air: Rigid PA), Industrial Fluids (Rigid PA), Industrial Fluids (Semi-Rigid PA), Air (Compressed Air: Semi-Rigid PA), Lubricants (Rigid PA) |
| Catalogue reference | Parker Legris Rectus Catalogue CAT-EN (Europe, July 2026), p.270 |
