Parker Hannifin Genuine
Parker Lucifer General Purpose 3/2 Anodized Aluminium Valve Pilot Operated 1/4"Bsp N/C NBR Orifice 6.5mm - No Coil - Coil Group 7.0/8.0
R10349,31
excl. VAT · per unit
Trade customer? Sign in for your tier price.
Out of stock · Replenishment on order
Or request a confirmed lead time for this SKU →
Maximum Operating Pressure
10 bar DC
Body Material
Anodized aluminium
Coil Temperature Range
-
Overview
Parker Lucifer General Purpose 3/2 Anodized Aluminium Valve Pilot Operated 1/4"Bsp N/C NBR Orifice 6.5mm - No Coil - Coil Group 7.0/8.0
Specifications
| Coil Temperature Range | - |
|---|---|
| Actuation Type | Pilot Operated |
| Minimum Fluid Temperature | -10 °C |
| Coil Specifications Met | - |
| ATEX Specifications Met | - |
| Specifications Met | Intrinsically safe. Pilot in FKM. |
| Port Type | PIPE MOUNTING |
| Maximum Operating Pressure | 10 bar DC |
| Function | NORMALLY CLOSED |
| Maximum Fluid Temperature | +75°C |
| Flow Coefficient | 10 l/min |
| Orifice Size | 6.5 mm |
| Port Size | G 1/4 |
| Valve Type | 3/2 way |
| Body Material | Anodized aluminium |
| Seal Material | NBR |
