Parker P1A Series ISO 6432 20mm Bore x 25mm Stroke Mini Round Cylinder STD Temp c/w Magnet Non-Adj Cushion
Overview
Parker P1A Mini ISO 6432 Cylinders are small-bore double-acting pneumatic actuators with magnetic piston, available in bores 10 to 25 mm. Designed for compact actuation in light-duty pneumatic circuits, with stainless-steel piston rod and ISO 6432 mounting interface. Parker P1A clevises and brackets provide a full pivot-mounting accessory range.
Markets:
- Industrial automation
- Light manufacturing
- Packaging
Applications:
- Small-bore actuation
- Light-duty positioning
- Compact installation
Features/Benefits:
- ISO 6432 standard mini cylinder
- Magnetic piston for sensor compatibility
- Stainless steel piston rod
- Wide pivot-mounting accessory range
- 10 bar operation
Specifications
| Standard | ISO 6432 mini round cylinder |
|---|---|
| Bore | 20 mm |
| Stroke | 25 mm |
| Action | Double acting, fixed (non-adjustable) cushioning |
| Maximum Operating Pressure | 10 bar |
| Working media | Dry, filtered compressed air (ISO 8573-1 class 3.4.3) |
| Seals | Standard NBR |
| Temperature Range | -20°C to +80°C |
| Piston | Magnetic piston |
| Piston rod diameter | 8 mm |
| Piston rod thread | M8 |
| Port thread | G1/8 |
| Theoretical force at 6 bar (out) | 188 N |
| Theoretical force at 6 bar (return) | 158 N |
| Catalogue reference | Parker Pneumatic P1A Mini ISO Cylinder Catalogue PDE2564TCUK, p.14 |
