Parker Hannifin Genuine
Product image not available
Parker Rectus 1/8 Male Coupler
R256,74Login for your trade price
excl. VAT · per unit
Trade customer? Sign in for your tier price.
On backorder · approx. 25 days
Or request a confirmed lead time for this SKU →
Maximum Operating Pressure
35 bar
Hex Size
14 mm
Body Material
Brass
Overview
Parker Rectus 1/8 Male Coupler
Specifications
| Function | Single Shut-Off |
|---|---|
| Coupling Half | Coupler |
| Connection Size | G 1/8 |
| Connection Type | Male BSPP ISO 228 Parallel |
| Maximum Operating Pressure | 35 bar |
| Temperature Range | -20°C to +100°C |
| Body Material | Brass |
| Seal Material | NBR |
| Sleeve Material | Brass |
| Flow Rate | 7 L/min (water), 550 L/min (air) |
| Diameter | 5 mm (nominal) |
| Hex Size | 14 mm |
| Outside Diameter | 16 mm |
| Weight | 0.026 kg |
| Valve Type | Standard Valve |
| Interchange Type | European Profile |
| Compatible Fitting | Series 21 Plug |
| For Fluid Type | Water (Industrial, drinking, treated water) |
| Product Series | Series 21 |
| Product Type | Pneumatic Quick Couplings |
| Plating Type | Without Surface Treatment |
| Region of Origin | Germany |
| Quantity per Box | 10 |
| Shape | Straight |
| Application | Industrial Machinery, Food & Beverages, Textile Machinery, Electronics, Medical, Pharma, Energy Management, Air & Gas Compressor, Trucks & Trailers, Safety & Rescue |
| Catalogue reference | Parker Legris Rectus Catalogue CAT-EN (Europe, July 2026), p.125 |
Documents
Catalogues Literature
Parker Legris Rectus Catalogue CAT-EN (Europe, July 2026) – catalogue page for this product (p.125)
Parker Legris Rectus General Catalogue (Europe) – full catalogue
Catalogues & Literature
Catalogue Page Parker Rectus Series 21 Brass/Steel
Datasheet Series 21 DryBreak Version
Catalogue Page Parker Rectus Series 21 Stainless Steel
Datasheet Series 21 Double-Shut-Off Version
Datasheet Series 21 Single-Shut-Off Version
Demos & Tutorials
Parker LPCE--Product Toturial : Electronics, Connection Solutions for Thermal Management
Parker Rectus--Product Demo : KL Shut-off System - Leak-Free Quick Coupling
Parker Rectus--Product Demon : KB Shut-off System - Double Shut-off Quick Coupling
Parker Rectus--Product Demo : KA Shut-off System - Single Shut-off Quick Coupling
Parker LPCE--Product Tutorial : Power Generation, Connection Solutions for Thermal Management
Compliance · Certifications · Safety
Enquire about this part
The fastest way to get a price on this SKU is to email our quote desk — your reply lands with an engineer within 4 business hours.
Email a quote request Or use the quote form →
