Parker Legris LF3000 8mm Equal Mixed Bulkhead Connector
Parker Legris LF3000 straight, 8 mm tube, technical polymer, vacuum to 20 bar, -20 °C to +80 °C.
Overview
The Parker Legris LF3000 8mm Equal Mixed Bulkhead Connector is a straight pneumatic push-in fitting designed for reliable tube-to-tube connections in low-pressure fluid and gas handling applications.
This connector delivers consistent performance across textile manufacturing, power generation, and process air systems where dependable leak-free connections are essential. The bulkhead design allows installation directly into panel walls or equipment housings, simplifying system layout and reducing external tubing runs. Its nickel-plated brass body withstands operating temperatures from −20 °C to 80 °C, whilst the stainless steel gripping ring and NBR seals ensure durability and compatibility with a wide range of industrial fluids.
The 8mm outer diameter tube connection accommodates standard pneumatic tubing, and the hexagon metric body (18mm hex size) permits straightforward installation and maintenance using conventional hand tools. Supplied in boxes of ten, this fitting serves automation engineers, maintenance technicians, and system integrators across industrial automation, textile processing, power generation, and instrumentation applications.
Specifications
| Product Series | LF 3000® |
|---|---|
| Product Type | Pneumatic Push-In Fittings - LF 3000® |
| Shape | Straight |
| Configuration | Tube to Tube |
| Connection 1 Type | Tube |
| Connection 1 Size | 8 mm Tube O.D. |
| Connection 2 Size | 8 mm Tube O.D. |
| Hex Size | 18 |
| Hex Type | Hexagon Metric |
| Body Material | Brass, Nickel-plated |
| Seal Material | NBR |
| Gripping Ring Material | Stainless Steel |
| Maximum Operating Pressure | 20 bar (usable from vacuum to 20 bar) |
| Vacuum Pressure Rating | 755 mm-Hg |
| Temperature Range | -20°C to +80°C |
| For Fluid Type | Air (Compressed Air), Other Fluids: Please Consult Us |
| Application | Automotive, Vacuum, Pneumatics, Packaging, Robotics, Textile |
| Specifications Met | ISO 14743, PED, RoHS, REACH |
| Weight | 0.036 kg |
| Quantity per Box | 10 |
| Catalogue reference | Parker Legris Rectus Catalogue CAT-EN (Europe, July 2026), p.21 |
