Parker Hannifin Genuine
Parker P1P Series ISO 21287 20mm Bore x 30mm Stroke Compact STD Cylinder STD Temp Female
R956,72Login for your trade price
excl. VAT · per unit
Trade customer? Sign in for your tier price.
Out of stock · Replenishment on order
Or request a confirmed lead time for this SKU →
Temperature Range
-20 to 80 °C
Working media
Dry filtered compressed air (ISO 8573-1 class 3.4.3)
Size
bore 20 mm, stroke 30 mm
Overview
Parker P1P Series ISO 21287 20mm Bore x 30mm Stroke Compact STD Cylinder STD Temp Female
Specifications
| Size | bore 20 mm, stroke 30 mm |
|---|---|
| Temperature Range | -20 to 80 °C |
| Pressure | 0.5–10 bar |
| Working media | Dry filtered compressed air (ISO 8573-1 class 3.4.3) |
| Description | P1P compact ISO 21287 cylinder, bore 20 mm, stroke 30 mm, double acting, female piston rod thread, magnet fitted. Seals: |
| Application | short-body actuation where axial space is tight; standard or guided, double acting or single acting |
| Catalogue reference | Parker Pneumatic P1P Pneumatic Cylinders Catalogue PDE2660TCUK, p.9 |
Documents
Catalogues Literature
Enquire about this part
The fastest way to get a price on this SKU is to email our quote desk — your reply lands with an engineer within 4 business hours.
Email a quote request Or use the quote form →
