Parker Legris LF3000 10mm - 1/2"Bspp Female Stud Fitting
Parker Legris LF3000 straight, 10 mm tube to G 1/2, technical polymer, vacuum to 20 bar, -20 °C to +80 °C.
Overview
The Parker Legris LF3000 is a push-to-connect stud fitting designed for automotive and mobile pneumatic applications requiring reliable tube-to-port connections. This straight fitting accommodates 10 mm outer diameter tubing with a G 1/2 female BSPP port, making it suitable for low-pressure fluid and compressed air systems operating between −20 °C and 80 °C. The nickel-plated brass body combined with a stainless steel gripping ring ensures durability and corrosion resistance in demanding environments, whilst the NBR seal delivers consistent performance across a wide operating range with a vacuum rating of 755 mm-Hg. The 24 mm hexagon metric design facilitates straightforward installation and maintenance. Supplied in convenient packs of 10, this fitting serves transportation, industrial automation, and process air systems where quick-connect reliability and compact design are essential.
Specifications
| Product Series | LF 3000® |
|---|---|
| Product Type | Pneumatic Push-In Fittings - LF 3000® |
| Shape | Straight |
| Configuration | Tube to Port |
| Connection 1 Type | Tube |
| Connection 1 Size | 10 mm Tube O.D. |
| Connection 2 Type | BSPP, Female |
| Connection 2 Size | G 1/2 inch Thread |
| Hex Size | 24 |
| Hex Type | Hexagon Metric |
| Body Material | Brass, Nickel-plated |
| Seal Material | NBR |
| Gripping Ring Material | Stainless Steel |
| Maximum Operating Pressure | 20 bar (usable from vacuum to 20 bar) |
| Vacuum Pressure Rating | 755 mm-Hg |
| Temperature Range | -20°C to +80°C |
| For Fluid Type | Air (Compressed Air), Other Fluids: Please Consult Us |
| Application | Textile, Vacuum, Robotics, Packaging, Pneumatics, Automotive |
| Specifications Met | ISO 14743, PED, RoHS, REACH |
| Weight | 0.048 kg |
| Quantity per Box | 10 |
| Catalogue reference | Parker Legris Rectus Catalogue CAT-EN (Europe, July 2026), p.14 |
