Parker Legris LF3000 16mm - 1/2"Bspp Female Stud Fitting
Parker Legris LF3000 straight, 16 mm tube to G 1/2, technical polymer, vacuum to 20 bar, -20 °C to +80 °C.
Overview
The Parker Legris LF3000 is a pneumatic push-to-connect stud fitting designed to join 16 mm tubing to G 1/2 female BSPP ports in low-pressure fluid and gas systems.
This fitting delivers reliable, leak-free connections without tools or fittings expertise. The stainless steel gripping ring secures the tube firmly whilst the nickel-plated brass body with NBR seals ensures durability across pneumatic and instrument air applications. Operating reliably between −20 °C and 80 °C with a vacuum rating of 755 mm-Hg, the LF3000 suits process control, automation, and equipment requiring quick, maintenance-free assembly.
The straight configuration and 27 mm hexagon body facilitate secure installation and disconnection in confined spaces. Supplied in boxes of five, these fittings are ideal for original equipment manufacturers and maintenance teams building modular pneumatic systems. The LF3000 serves transportation, industrial automation, and process industries worldwide.
Specifications
| Product Series | LF 3000® |
|---|---|
| Product Type | Pneumatic Push-In Fittings - LF 3000® |
| Shape | Straight |
| Configuration | Tube to Port |
| Connection 1 Type | Tube |
| Connection 1 Size | 16 mm Tube O.D. |
| Connection 2 Type | Female, BSPP |
| Connection 2 Size | G 1/2 inch Thread |
| Hex Size | 27 |
| Hex Type | Hexagon Metric |
| Body Material | Brass, Nickel-plated |
| Seal Material | NBR |
| Gripping Ring Material | Stainless Steel |
| Maximum Operating Pressure | 20 bar (usable from vacuum to 20 bar) |
| Vacuum Pressure Rating | 755 mm-Hg |
| Temperature Range | -20°C to +80°C |
| For Fluid Type | Air (Compressed Air), Other Fluids: Please Consult Us |
| Application | Automotive, Packaging, Textile, Robotics, Vacuum, Pneumatics |
| Specifications Met | ISO 14743, PED, RoHS, REACH |
| Weight | 0.096 kg |
| Quantity per Box | 5 |
| Catalogue reference | Parker Legris Rectus Catalogue CAT-EN (Europe, July 2026), p.14 |
